Nominal Value |
Standard Tolerance (±)
|
Disc/Ring/Cylinder (Tube): Outer Diameter
|
|
<1.000″ | 0.010″ |
≥1.000″ to <1.500″ | 0.015″ |
≥1.500″ to <2.000″ | 0.025″ |
≥2.000″ | 0.040″ |
<25 mm | 0.25 mm |
≥25 mm to <38 mm | 0.38 mm |
≥38 mm to <50 mm | 0.60 mm |
≥50 mm | 1.00 mm |
Ring/Cylinder (Tube): Inner Diameter
|
|
<0.250″ | 0.010″ |
≥0.250″ to <0.500″ | 0.015″ |
≥0.500″ to <1.000″ | 0.020″ |
≥1.000″ | 0.025″ |
<6 mm | 0.25 mm |
≥6 mm to <13 mm | 0.38 mm |
≥13 mm to <25 mm | 0.50 mm |
≥25 mm | 0.60 mm |
Plate: Length or Width
|
|
<0.500″ | 0.005″ |
≥0.500″ to <1.000″ | 0.010″ |
≥1.000″ to <1.500″ | 0.015″ |
≥1.500″ to <2.000″ | 0.025″ |
≥2.000″ | 0.040″ |
<13 mm | 0.13 mm |
≥13 mm to <25 mm | 0.25 mm |
≥25 mm to 38 mm | 0.38 mm |
≥38 mm to <50 mm | 0.60 mm |
≥50 mm | 1.00 mm |
All Parts: Thickness
|
|
0.008″ to <0.200″ | 0.001″ |
≥0.200″ | 0.002″ |
0.20 mm to <5.00 mm | 0.025 mm |
≥5.00 mm | 0.05 mm |
Irregularity | Linear Std. Dimen. | Allowable Size | Linear Metric Dimen. | Allowable Size |
Physical Chips | <0.250″ | ≤0.040″ | <6.35mm | ≤1.00mm |
≥0.250″ <0.500″ | ≤0.080″ | ≥6.35mm <13.00mm | ≤2.00mm | |
≥0.500″ <1.000″ | ≤0.100″ | ≥13.00mm <25.00mm | ≤2.50mm | |
≥1.000″ | ≤0.125″ | ≥25.00mm | ≤3.17mm | |
Silver Flaws |
Total combined area of silver flaws is not to exceed 0.5% of total electrode area
|
|||
Cracks |
Parts are to be free of cracks
|
|||
Standard physical inspections are performed with no magnification, roughly 12″ from workspace
|
Please be specific when requesting parts, tolerances, or electrode patterns. Provide drawings or sketches for parts or electrode patterns, and include ID tolerance if requesting rings or cylinders (tubes). For custom electrical leads, please specify AWG and length and provide a drawing showing the desired locations.
